Slimline
    System
Kömmerling Aluminium

Slimline System

KS42.1 SL ES

[Majestic]

Striking the perfect balance between refined aesthetics and robust structural capability, the KS42.1 SL ES [Majestic] is a 33 mm sleek interlock sliding system engineered for large-format openings in high-specification residential and commercial environments.
With a versatile two and three-track frame, integrated stainless steel guiderail, flyscreen option, and a 300 kg per panel roller capacity, it delivers a seamless, high-performance sliding experience across every configuration.

Sleek Precision
33 mm Interlock

High Load Capacity
300 kg per Panel

Versatile Tracks
2 & 3 Track with SS Guiderail

The KS42.1 SL ES [Majestic] supports up to 6 panels with a maximum individual panel size of 1.5 m (w) × 3.0 m (h), enabling expansive, light-filled openings for contemporary living spaces, hotel lobbies, and commercial facades of the highest specification.

Two-track and three-track frame configurations with a stainless steel guiderail and inside lip provision give project teams full flexibility to adapt the system to varying opening widths, design briefs, and site-specific requirements – with an optional integrated flyscreen for added comfort and functionality.

The 33 mm sleek interlock width maintains clean, uninterrupted sightlines across all panel counts, while the system’s compatibility with SG, DGU, and laminated DGU glazing from 5 to 32 mm ensures it meets the full range of thermal, acoustic, and safety glazing specifications demanded by today’s premium projects.

CRAFTED FOR PERFORMANCE

System Features

The KS42.1 SL ES [Majestic] is a robustly engineered sliding system with a wind load resistance of up to 2.75 kPa, making it well-suited to exposed façades, elevated floors, and climatically demanding project environments across the region.

High-performance rollers capable of bearing up to 300 kg per panel guarantee smooth, consistent operation across the full range of panel sizes, ensuring the system performs as effortlessly in daily use as it does at first installation.

The stainless steel guiderail, inside lip detail, and optional flyscreen provision are fully integrated into the system architecture, while a comprehensive multiple locking mechanism delivers the elevated security standard expected in high-value residential and commercial installations.

Sleek 33 mm interlock

2 & 3 track configuration

AWARDS & CERTIFICATIONS
KS42.1 Sl ES_Winwall (140 x 100 px)

Performance Test
Certificate
AWARDS & CERTIFICATIONS
Portfolio_IN_920x600pxNakheel Tower

Sustainability
Certifications
Portfolio_IN_920x600pxNakheel Tower

Sustainability
Certifications
Portfolio_IN_920x600pxNakheel Tower

Sustainability
Certifications
  • Large-format panel capacity of 1.5 m (w) × 3.0 m (h) enables floor-to-ceiling glazed openings for high-specification residential and commercial projects
  • Up to 6 panels supported, delivering wide, uninterrupted panoramic openings across living areas, terraces, and commercial facades
  • Sleek 33 mm interlock width maintains refined sightlines and a slim visual profile across all panel counts and configurations
  • Two-track and three-track frame options with SS guiderail and inside lip provision ensure complete flexibility for varying project layouts
  • Integrated flyscreen option adds practical comfort without compromising the system's clean aesthetics or sightlines
  • Wind load capacity of up to 2.75 kPa delivers reliable performance in exposed, elevated, and climatically demanding locations
  • High-load rollers rated at 300 kg per panel guarantee smooth, consistent operation throughout the system's lifetime
  • Glass compatibility spanning SG, DGU, and laminated DGU from 5–32 mm meets diverse thermal, acoustic, and safety glazing specifications
  • Multiple locking provision delivers a high level of security across all panel configurations for both residential and commercial use
  • Consistent 33 mm interlock geometry across two-track and three-track variants simplifies cutting, machining, and panel assembly
  • Shared profile system across 2- and 3-track configurations reduces inventory complexity and streamlines procurement
  • Wide glass thickness range (5-32 mm) covering SG, DGU, and laminated DGU minimises the need for bespoke glazing adaptors
  • SS guiderail integrates within the standard track profile, eliminating the need for additional floor-level components or secondary operations
  • Flyscreen option uses compatible profile components from within the same system, keeping the bill of materials lean and consistent
  • High-load roller assembly integrates within the standard frame, avoiding additional structural reinforcement during fabrication

KS42.1 SL ES

System Name42 mm (D) x 70 mm (H)
Thermally brokenNo
Glass Thickness5-32 mm
Full hidden DrainageNo (Drainage Cap remains visible)
Thermal Insulation Uf-
Sound IsolationDesigned for deduction upto 30 db
Rw (C;Ctr)-
STC-
OITC-
Wind Resistance
Tested according EN 122112750 Pa
Classified according EN 12210Class BE 2750
Water Tightness
Tested according EN 1027300 Pa
Classified according EN 12208Class 7A
Air Permeability
Tested according EN 1026600 Pa
Classified according EN 12207Class 3
MaterialAluminium alloy 6063 T6
Size Limitations1500 x 3000 mm

The KS42.1 SL ES [Majestic] is a 33 mm sleek interlock aluminium sliding system available in two-track and three-track frame configurations with a stainless steel guiderail and inside lip provision. The system supports up to 6 panels with a maximum individual panel size of 1.50 m (w) × 3.00 m (h) and a panel load-bearing roller capacity of up to 300 kg. Glass types including single glazing (SG), double-glazed units (DGU), and laminated DGU are accommodated, with glass thickness ranging from 5 mm to 32 mm. Wind load capacity is rated up to 2.75 kPa. An optional flyscreen provision is available within the same system architecture. Multiple locking mechanisms are incorporated to ensure a high level of security.

The KS42.1 SL ES [Majestic] is suited to large-format high-specification residential and commercial sliding applications where sleek sightlines, versatile track configuration, high load capacity, and robust weather performance are required.

KS42.1 SL ES

Profile basic depths42 mm
Profile Face Widths70 mm
